SW520D Mercury Tilt Switch Sensor Module



  • Working voltage:3.3V-12V
  • With screw mounting hole
  • Adopts LM393 comparator
Add to Wishlist
Add to Wishlist

The SW520D Mercury Tilt Switch Sensor Module stands as a pivotal component in sensing technology, providing a straightforward and efficient solution for detecting tilt and orientation changes in various applications.

Transitioning to its core features, this sensor module incorporates a sensitive SW520D mercury tilt switch, designed to detect changes in tilt angles with precision. Its compact design and simplicity make it an ideal choice for applications where accurate tilt sensing is crucial.

Moreover, the module’s versatility extends to its compatibility with various microcontrollers and development boards, allowing seamless integration into electronic projects and prototypes.

In terms of construction, the SW520D Mercury Tilt Switch features a straightforward design, so enhancing ease of installation and integration. Its adaptability caters to both beginners and experienced electronics enthusiasts.

Furthermore, the sensor module interfaces with microcontrollers, so enabling real-time monitoring and response to changes in tilt angles. This integration ensures that but the module aligns with the specific requirements of diverse applications, from interactive toys to orientation-sensitive electronic devices.

In practical terms, the SW520D Mercury Tilt Switch Sensor plays a pivotal role in applications where tilt detection is essential. Its ability to trigger responses based on tilt angles adds a layer of responsiveness to electronic projects and devices requiring orientation sensitivity.


  • Adopts high sensitivity ball switch SW-520D angle sensor
  • Comparator output, high drivability, over 15ma current
  • Working voltage:3.3V-12V
  • With screw mounting hole
  • Adopts LM393 comparator
  • The output format: digital switching outputs (0 and 1)
  • A fixed bolt holes for easy installation
  • Small PCB board size: 3.2cm x 1.4cm
  • Using a wide voltage LM393 comparator

To Learn More Visit our Website

For more information:-www.mifraelectronics.com
* Product Images are shown for illustrative purposes only and may differ from actual product.

Packages includes:-

  • 1 x SW520D Mercury Tilt Switch Sensor Module.
